TECHNICAL DATA OF ORGAN BLOWERS OF TYPE LVM2
3360 rotations/minute 60 Hz Pressure range: 750-800 Pa
TYPE	For organ stops up to app.	For reed organ sets app.	Wind production CFM	Wind pressure		Motor power h.p.	Net weight app. pound
1-ph.A.C., 120V	For organ stops up to app.	For reed organ sets app.	Wind production CFM	Pa	inch	Motor power h.p.	Net weight app. pound
LVM2/1-003-075/120V	5	-	106	750	2-61/64"	0,09	19,84
LVM2/2-003-075/120V	-	10	106	750	2-61/64"	0,09	19,84
LVM2/3-003-075/120V	5	-	106	750	2-61/64"	0,09	23,14
LVM2/1-005-080/120V	6	-	177	800	3-1/8"	0,11	24,25
LVM2/2-005-080/120V	-	12	177	800	3-1/8"	0,11	24,25
LVM2/3-005-080/120V	6	-	177	800	3-1/8"	0,11	27,55
