THE MANUFACTURING OF ORGAN BLOWERS AND OTHER HIGH-PRESSURE CENTRIFUGAL FANS





TECHNICAL DATA OF ORGAN BLOWERS OF TYPE LVM4

1680 rotations/minute 60 Hz
Pressure range: 1 200 Pa
TYPE
For organ stops up to app.
Wind production
CFM

Wind pressure
Motor power
h.p.
Net weight app. pound
3-ph.A.C.: 208V
1-ph.A.C.: 240V
Pa
inch
LVM4-008-120/208V LVM4-008-120/240V 17-20 282 1200 4-3/4" 0,53
200,62
LVM4-014-120/208V LVM4-014-120/240V 28-32 494 1200 4-3/4" 0,76 216,05
LVM4-021-120/208V LVM4-021-120/240V 40-45 742 1200 4-3/4" 1 251,33
LVM4-028-120/208V - 50-55 989 1200 4-3/4" 1,6 271,17
LVM4-035-120/208V - 60-65 1 236 1200 4-3/4" 2,01 282,19
LVM4-043-120/208V - 68-72 1 518 1200 4-3/4" 2,54 365,97
LVM4-052-120/208V - 78-85 1 836 1200 4-3/4" 3 370,38
LVM4-062-120/208V - 89-100 2 189 1200 4-3/4" 3,62 372,58
